Flutter

Flutter 是一个基于 Dart 的跨平台开发框架

性能接近原生，采用 GPU 渲染，应用的刷新频率高 ( 每秒帧数高，不卡顿 )

下载安装

asdf

# 0. 下载 asdf 对 Flutter 支持的前提库
% brew install jq

# 1. 下载 asdf 插件与 flutter 的版本
% asdf plugin add flutter
% asdf install flutter [版本]

# 2. 设置全局环境下的版本
% asdf global flutter [版本]
% asdf reshim flutter

# 3. 一劳永逸将所有的 Dart 的第三方工具添加到环境变量
% export PATH="$PATH":"$HOME/.pub-cache/bin" >> ~/.zshrc
% source ~/.zshrc

如下：本文使用 Flutter v3.24.0 + Dart v3.5.0

% dart --version
Dart SDK version: 3.5.0 (stable) (Tue Jul 30 02:17:59 2024 -0700) on "macos_arm64"
% flutter --version
Flutter 3.24.0 • channel stable • https://github.com/flutter/flutter.git
Framework • revision 80c2e84975 (5 months ago) • 2024-07-30 23:06:49 +0700
Engine • revision b8800d88be
Tools • Dart 3.5.0 • DevTools 2.37.2

Flutter SDK 的下载位置

% asdf where flutter
/Users/[用户名]/.asdf/installs/flutter/[版本]

环境配置

Flutter 下载完成后需要检查开发环境、以及相关的工具链和依赖项是否完备

% flutter doctor

例子：开发环境不配备 Android Studio、Xcode 时 ( 仅用于 Web 开发 )

% flutter doctor
Doctor summary (to see all details, run flutter doctor -v):
[✓] Flutter (Channel stable, 3.24.0, on macOS 13.2.1 22D68 darwin-arm64, locale zh-Hans-JP)
[✗] Android toolchain - develop for Android devices
    ✗ Unable to locate Android SDK.
      Install Android Studio from: https://developer.android.com/studio/index.html
      On first launch it will assist you in installing the Android SDK components.
      (or visit https://flutter.dev/to/macos-android-setup for detailed instructions).
      If the Android SDK has been installed to a custom location, please use
      `flutter config --android-sdk` to update to that location.

[✗] Xcode - develop for iOS and macOS
    ✗ Xcode installation is incomplete; a full installation is necessary for iOS and macOS development.
      Download at: https://developer.apple.com/xcode/
      Or install Xcode via the App Store.
      Once installed, run:
        sudo xcode-select --switch /Applications/Xcode.app/Contents/Developer
        sudo xcodebuild -runFirstLaunch
    ✗ CocoaPods not installed.
        CocoaPods is a package manager for iOS or macOS platform code.
        Without CocoaPods, plugins will not work on iOS or macOS.
        For more info, see https://flutter.dev/to/platform-plugins
      For installation instructions, see https://guides.cocoapods.org/using/getting-started.html#installation
[✓] Chrome - develop for the web
[!] Android Studio (not installed)
[✓] VS Code (version 1.95.3)
[✓] Connected device (2 available)
[✓] Network resources

! Doctor found issues in 3 categories.

VSCode 插件配置

{
  "dart.flutterSdkPath": "/Users/[用户名]/.asdf/installs/flutter/[版本]",
  "dart.previewFlutterUiGuides": true,
  "dart.previewFlutterUiGuidesCustomTracking": true,
  // "dart.closingLabels": false
}

项目初始化

项目名使用小写蛇形命名 ( snake_case )

# 1. 创建项目，进入项目目录
% flutter create [项目名]
% cd [项目名]

# 2. 启动项目
% flutter run
Connected devices:
macOS (desktop) • macos  • darwin-arm64   • macOS 13.2.1 22D68 darwin-arm64
Chrome (web)    • chrome • web-javascript • Google Chrome 131.0.6778.140

No wireless devices were found.

[1]: macOS (macos)
[2]: Chrome (chrome)
Please choose one (or "q" to quit): 2
Launching lib/main.dart on Chrome in debug mode...
Waiting for connection from debug service on Chrome...              7.2s
This app is linked to the debug service: ws://127.0.0.1:63280/9IKi7KotlxM=/ws
Debug service listening on ws://127.0.0.1:63280/9IKi7KotlxM=/ws

🔥  To hot restart changes while running, press "r" or "R".
For a more detailed help message, press "h". To quit, press "q".

A Dart VM Service on Chrome is available at: http://127.0.0.1:63280/9IKi7KotlxM=
The Flutter DevTools debugger and profiler on Chrome is available at: http://127.0.0.1:9101?uri=http://127.0.0.1:63280/9IKi7KotlxM=

在启动状态的 flutter 项目终端的命令行中可以使用快捷指令

常用快捷命令	说明
r	热重载 ( Hot Reload)
R	重启
q	中止并退出
p	切换辅助线的展示
o	切换不同操作系统下的展示样式

项目目录结构

目录与文件使用蛇形命名 ( snake_case )

目录结构

[项目目录]
├─ .dart_tool/
│
├─ android/               # Android 原生目录
├─ ios/                   # IOS 原生目录
├─ linux/                 # Linux 原生目录
├─ macos/                 # MacOS 原生目录
├─ windows/               # Windows 原生目录
├─ web/                   # Web 项目目录
│
├─ build/
├─ test/
│
├─ lib/                   # 存放项目中的 Dart 代码
│  └─ main.dart           # 项目入口文件
│
├─ analysis_options.yaml
├─ pubspec.yaml
├─ pubspec.lock
│
└─ ...

常用命令

	说明
flutter create	创建项目
flutter run	启动项目
flutter build [web|apk|ios|macos|linux|windows]	构建项目 基于选项生成项目的构建目录build
flutter clean	清空项目生成的文件 执行后需要重新下载项目中的依赖包

组件化

Widget

Flutter 中一切皆组件，组件构建界面的基本单元

界面上所有元素可视化的元素、控件或者布局都可以看作是一个组件

组件的实质都为 Dart 类，使用时需要通过实例化创建组件的实例对象

lib/main.dart

import 'package:flutter/material.dart';

void main() {
  runApp(
    MaterialApp(
      home: Scaffold(
        body: 其他组件实例,
      ),
    ),
  );
}
